WiiM Vibelink Amp - Unleash the Power of Pure Sound (Amplifier , แอมป์พลิไฟเออร์)

Dimensions and Weight

Dimensions:

• 7.9 x 7.9 x 2.58 inches (200 x 200 x 63 mm)

Weight:

• 2.05 kg (4.5 lbs)

Power input:

• 100-240V, 50/60Hz AC, 3A Max

Power & Amplification

Output Power :

• 100W per channel at 8Ω (stereo)

Amplifier Technology :

• Class-D with PFFB (Post-Filter Feedback) technology

Total Harmonic Distortion (THD+N) :

• 0.0005%

Signal-to-Noise Ratio (SNR) :

• 120dB

Frequency Response:

• 20Hz 20kHz ± 0.5dB

Impedence Range:

• 3~8 ohms

Audio Processing

Premium DAC :

• ESS 9039Q2M high-performance DAC

Bit-Perfect Playback :

• Supports up to 192kHz/24-bit audio

Dynamic Range :

• 120dB for high-resolution sound

Pure Analog Input :

• No ADC conversion, maintaining signal integrity

Input & Output Options

Analog Inputs:

• 1x RCA Stereo (Line-In, pure analog signal path)

Digital Inputs:

• 1x Optical (TOSLINK) Up to 192kHz/24-bit
• 1x Coaxial (S/PDIF) Up to 192kHz/24-bit

Speaker Outputs:

• Gold-plated binding posts (supports banana plugs or bare wire connections)

Trigger & Power Management:

• 12V Trigger In: Auto power-on with compatible devices

Auto Standby Mode:

• Powers down after 30 or 60 minutes of inactivity

Supported Audio Formats

• PCM up to 192kHz/24-bit (through digital sources)

Control Interfaces

Volume Knob:

• Adjusts volume

LED Indicator:

• Three 4-color RGBW LED indicates source input and device status

Build & Design

Chassis:

• Premium unibody aluminum for durability & heat dissipation

Thermal Management:

• Copper heat pipe, large aluminum heatsink, unibody aluminum case, and precision PID thermal control

Cooling System:

• Passive, silent operation

Package Contents

• Use Guide *1
• Power Cable *1
• RCA Cable *1
• Optical Cable *1
• Banana Plugs *4
