iFi Audio NEO iDSD 3 - Hi-Res Desktop DAC & Lossless Audio Bluetooth Amp

Embrace The New.

    Merging purist design principles with the latest features from across our range, the NEO iDSD brings the best of iFi audio together in a complete, all-in-one home audio package.

Specifications

ANALOGUE INPUTS
    • Single-Ended RCA (L/R)
BLUETOOTH FORMATS
    • aptX Lossless, aptX Adaptive, aptX, LDAC, LHDC/HWA, AAC, SBC
DIGITAL INPUTS
    • Bluetooth 5.4;
    • USB-B 3.0;
    • S/PDIF Coaxial;
    • S/PDIF Optical;
DIMENSIONS
    • 214 x 158 x 41mm (8.4 x 6.2 x 1.6”)
FILE SUPPORT
    • 768kHz PCM; DSD512 (22.6 MHz)
HEADPHONE OUTPUT
    • Balanced 4.4mm; Single-Ended 6.3mm
HEADPHONE OUTPUT IMPEDANCE
    • ≤1Ω; ≤7Ω when iEMatch enabled
HEADPHONE OUTPUT RMS
    • 4.4mm ≥12.7V/2,532mW @ 64Ω (RMS)
    • 6.3mm ≥8.4V/2,244mW @ 32Ω (RMS)
LINE OUTPUTS
    • Balanced XLR (L/R): ≤19.5V (variable); 4.4V (fixed)
    • Single-Ended RCA (L/R): ≤10.5V (variable); 2.2V (fixed)
LINE OUTPUT IMPEDANCE
    • XLR ≤102Ω; RCA ≤51Ω
NET WEIGHT
    • 916g (2.0lbs)
SNR+DNR
    • ≥120dB(A) @ -60dBFS
THD+N
    • ≤0.0015% @ 0dBFS
POWER SUPPLY REQUIREMENT
    • DC 9V/1.5A-15V/0.9A (centre +ve)
