Bowers & Wilkins (B&W) 606 S3 - Bookshelf Speakers (ลำโพงตู้)

Key-Highlight

• 1 x 1" Decoupled Titanium Dome Tweeter
• 1 x 6.5" Continuum Cone Mid/Woofer
• 40 Hz to 33 kHz Frequency Response
• Supports 30 to 120W at 8 Ohms
• Acoustically Transparent Tweeter Grille

Details & Specifications

Size & weight

Net weight

• 7.05kg (15.5 lb)

Dimensions

• Height: 344 mm (13.6 in) cabinet only
• Width: 189 mm (7.4 in) cabinet only
• Depth: 300 mm (11.8 in) cabinet only
• 328 mm (12.9 in) including grille and terminals

Technical details

Drive units

• 1x ø25mm (1 in) Titanium Dome high-frequency
• 1x ø165mm (6.5 in) Continuum cone bass / midrange

Frequency range

• -6dB 40Hz - 33kHz

Harmonic distortion

• 2nd and 3rd harmonics (90dB, 1m on axis)
• <1% 100Hz - 22kHz
• <0.5% 150Hz - 12kHz

Nominal impedance

• 8 (minimum 3.7)

Recommended amplifier power

• 30W - 120W into 8Ω on unclipped programme

Technical features

• Decoupled Double Dome Titanium tweeter
• Continuum cone bass / midrange
• Flowport

Description

• 2-way vented-box system

Max recommended cable impedance

• 0.1

Frequency response (+/-3dB from reference axis)

• 52Hz - 28kHz ±3dB

Sensitivity (on axis at 2.83Vrms at 1m)

• 88dB
