System Format
- 2.5-Way
Frequency Response (-6 dB)
- 45 25,000 Hz (Free field)
- 35 30,000 Hz (In room)
Sensitivity (2.83v @ 1m)
- 88 dB
Nominal Impedance
- 8 ohms
Minimum Impedance
- 4.4 ohms
Maximum SPL
- 112 dBA (pair)
Power Handling (RMS)
- 120 W
Recommended Amplifier Requirements
- 40 120 W
Bass Alignment
- Bass reflex Dual HiVe II port system
Crossover Frequency
- 700 Hz
- 2,400 Hz
Drive Unit Complement
- 2 x 51/2" C-CAM midbass driver
- 1 x 25 mm C-CAM Gold Dome tweeter with UD Waveguide
External Dimensions (Including Grille and Terminals (H x W x D))
- 886 x 166 x 265 mm (347/8 x 69/16 x 107/16")
External Dimensions (including Outrigger Feet and Spikes (H x W x D))
- 909 x 229 x 304 mm (3513/16 x 9 x 1115/16")
Weight (each)
- 12.8 kg (28 lb 4 oz)
Sold As
- Pair
